Structural Hex Bolt 10.9S for Steel Building

structural hex bolt 10.9S for steel building alloy steel black oxide GB/T 1228 A325 bolt nut washer set

A structural hex bolt 10.9S for steel building is a high strength hex head fastener used to connect steel frames, columns, beams and bracing in structural construction. This structural hex bolt 10.9S for steel building is made from alloy steel grade 10.9S with a black oxide finish, supplied to GB/T 1228 and ASTM A325, and delivered as a matched assembly set with one hex bolt, one hex nut and two washers for each joint.

What Is a Structural Hex Bolt 10.9S for Steel Building

The structural hex bolt 10.9S for steel building belongs to the high strength bolt group used in load-bearing steel connections. Its hex head provides a firm wrenching surface, and the controlled clamp force transfers the design load across the connected plates. Unlike ordinary general-purpose bolts, this 10.9S grade is heat treated to a high tensile strength and pre-tension capacity suitable for primary structural joints rather than light secondary attachments.

Each set leaves the factory as a matched assembly so the bolt, nut and washers share the same grade and hardness level. Mixing a high strength bolt with a lower strength nut or washer can weaken the joint, so supplying them together keeps the connection properties as designed. This structural hex bolt 10.9S for steel building fits both friction-type and bearing-type joints, depending on how the connection is specified.

Material, Grade and Surface Finish

The bolt is manufactured from alloy steel in grade 10.9S. The 10.9S designation indicates a high tensile strength class intended for main load-bearing steel connections, where consistent pre-tension and clamp are required. The surface finish is black oxide, which provides a dark protective layer over the steel core for indoor and covered structural service.

The black oxide finish is commonly selected for structural assemblies where the bolt is concealed inside the frame or protected from direct outdoor exposure. For externally exposed or coastal environments, the finish can be reviewed against the project specification during quotation. The grade marking and standard reference are identified on the bolt so inspectors can verify the fastener on site.

Standards and Assembly Set

This structural hex bolt 10.9S for steel building conforms to GB/T 1228 for the bolt dimension and is referenced to ASTM A325 for the structural bolt performance grade. The GB/T 1228 dimension applies to the heavy hex structural bolt, while ASTM A325 describes the heat treated steel structural bolt used in building and bridge connections.

Every complete assembly set includes:

  • 1 hex structural bolt
  • 1 matching hex nut
  • 2 washers

The two washers sit under the bolt head and under the nut to spread the clamping force and protect the faying surface. Ordering the complete set avoids mismatched threads, hardness levels and dimensions between the components.

Friction-Type and Bearing-Type Joints

The 10.9S structural hex bolt is used in two common connection types. In a friction-type joint, the tightened clamp holds the plates together and the load transfers through friction on the contact surfaces, which gives the joint better slip resistance under vibration and repeated load. In a bearing-type joint, the connected members bear against the bolt and force transfers through the bolt shank and bearing.

Whether a joint requires friction-type or bearing-type design depends on the project drawings, load conditions and relevant steel connection specification. The faying surface should be clean and free of loose scale, paint or oil where friction transfer is required. For background on high strength bolted joints and connection types, see this guide to structural bolt friction and bearing type connections.

Typical Applications

This structural hex bolt 10.9S for steel building is widely specified in:

  • Steel structure buildings and prefabricated warehouses
  • Bridges and tower projects
  • Heavy steel frame columns, beams and connections
  • Friction-type and bearing-type structural joints

It suits main frame connections where the assembly must retain clamp under service loads, and it can be matched to other fastening components in the same steel structure project. Related products in our fastener range include the carriage bolt DIN603 for lighter connections and our 10.9S heavy hex structural bolt assemblies for other structural configurations.

MOQ, Lead Time and OEM Service

The minimum order quantity is 1000 sets, and the bolts are supplied as matching assembly sets rather than loose components only. Sample orders are ready in 3 to 7 days, and bulk production lead time is 15 to 25 days depending on quantity and finish. We accept OEM and ODM service with custom marking and packing to your project requirement.

Send us your bolt diameter, length, standard reference and quantity, and our engineers will confirm the matching bolt, nut and washer set for your steel building project.
